Unit Description
37
AXA0227
1
2
34 5 6
1. Sensing Bulb Option for Recording Thermometer (Return Air)
2. Gas Sensor Unit for AFAM+ Option, see page 45
3. Filter for Gas Sensor for AFAM+ Option
4. Vent Loop for Gas Sensor for AFAM+ Option
5. Air Compressor for Humidity System Option, see 43
6. Humidity Sensor for Dehumidify Option or Humidity Option
Figure 7: CSR20SL, CSR20SL, CSR40SL & CSR40SL Options — Evaporator Front View
