Thermo King CSR Series User Manual

Unit Description
39
AXA0229
1
2
3
4
5
6
7
8
9
15
14
13
12
11
10
1. Evaporator Coil 9. Scroll Compressor (See page 40)
2. Coil/Dehumidify Valve 10. Discharge Tube (After 7/00)
3. Expansion Valve 11.
Discharge Tube with High Pressure Cutout
(Before 8/00)
4. Heat Exchanger 12. Condenser Coil
5. One-piece Filter Drier/In-line Filter 13. High Pressure Relief Valve
6. Stepper Motor Valve 14. Receiver Tank
7. Liquid Injection Solenoid Valve 15. Warm Gas Bypass Solenoid Valve
8. Low pressure Cutout Switch
Figure 9: Refrigeration System
