Thermo Scientific DensityPRO-T - Page 55

Specifications
Approvals
DensityPRO (MS2011DUI) &
DensityPRO-T Detector
(MS2011DUR); XP, XPW & 4X
Class I, Div 1, Groups B, C, D; T4
Class I, Div 2, Groups A, B, C, D; T4
Class II, Div 2, Groups E, F, G; T4
Class III; T4; Tamb: -40ºC to 75ºC
Enclosure type 4X
I M2 GD Ex d ib† IIB+ H2 Gb T4; Tmax: 125ºC
II 2 GD Ex d ib† IIB+ H2 Gb T4; Tamb: -40ºC to 75ºC SIRA
13ATEX1187
IECEx CSA 13.0013
IP66
Approvals
DensityPRO-T Transmitter
(MS2011T)
Class I, Div 2, Groups A, B, C, D; T4
Class II, Div 2, Groups E, F, G; T4
Class III; T4; Tamb: -40ºC to 75ºC
Enclosure type 4X
II 3 GD Ex nA nC ib† IIC T4 Gc; Tamb: -40ºC to 75ºC IECEx
CSA 13.0018X
IP66
Power
– 11 to 32 VDC, 770 mA max
– 100 to 240 VAC, 50/60 Hz, 380 mA max (MS2011DUI)
– 100 to 240 VAC, 50/60 Hz, 300 mA max (MS2011DUR &
MS2011T)
†
When ISIO PCA is installed
Thermo Scientific DensityPRO Installation Manual B-3
