Appendix C
Drawings
Note: Information presented in this chapter has been regenerated from
original drawings. Every effort is made to maintain document accuracy.
However, in order to enhance legibility, the documents may have been
restructured, and some information may have been intentionally excluded.
Therefore, the drawings within this guide may not be an exact duplicate of the
original drawings.
Note: Drawings in this manual are included for reference only and may not be
the current version. Contact the factory if you need a copy of the latest
revision.
Table C-1. Installation Wiring Diagrams
Drawing # Rev. Description Page
1-0700-038 A
Installation Wiring Diagram, Integrated System, DensityPRO
NAI (Model MS2011I) / DensityPRO (Model MS2011DUI)
C-3
1-0700-039 A
Installation Wiring Diagram, Remote System, DensityPRO
NAI+ ( Models MS2011R & MS2011T) / DensityPRO
(Models MS2011DUR & MS2011T)
C-7
Table C-2. Installation Drawings
Drawing # Rev. Description Page
4-0700-144 -
Installation Drawing, Remote System Detector with Explosion-
Proof Housing
C-10
4-0700-145 -
Installation Drawing, Remote System Detector with Explosion-
Proof Housing and Water-Cooled Jacket
C-11
4-0700-146 -
Installation Drawing, Remote System Detector with NEMA 4X
Housing and Quick Connects
C-12
4-0700-147 -
Installation Drawing, Remote System Detector with NEMA 4X
Housing
C-13
4-0700-148 -
Installation Drawing, Integrated System with Explosion-Proof
Housing
C-14
4-0700-149 -
Installation Drawing, Integrated System with Explosion-Proof
Housing and Water-Cooled Jacket
C-15
4-0700-150 -
Installation Drawing, Remote System Transmitter with NEMA
4X Housing
C-16
Thermo Scientific DensityPRO Installation Manual C-1
