Thermo Scientific TSX Series User Manual

28 | Operation Ultra Low Temperature Freezers
Figure 63. Primary Y-Axis Set screen
• The Secondary Y-Axis button allows the user to set the
temperature range. If Auto is selected, the temperatures
are automatically set. If Manual is selected, the user must
specify the high and low temperatures. Item associated
with the Secondary Y-Axis will be displayed as a dotted
line. The Axis On toggle button is used to enable the
Secondary Y-axis.
Figure 64. Secondary Y-Axis Set Screen
Event Icons
Icons related to events will appear on the top of the chart.
Icon Description
Door Open
Power Failure
Temperature Alarm
Service
Multiple Events
Connected to InstrumentConnect™
Connected to Wi-Fi

Thermo Scientific TSX Series Specifications

General

Type	Laboratory Refrigerator
Cooling Type	Forced air cooling
Defrost Type	Automatic
Door Type	Solid or glass door options
Controller Type	Microprocessor
Certifications/Compliance	UL, CE
Energy Consumption	Varies by model; refer to product specification sheet
Voltage	115V
Exterior Dimensions (H x W x D)	Varies by model; refer to product specification sheet
Interior Dimensions (H x W x D)	Varies by model; refer to product specification sheet
Weight	Varies by model; refer to product specification sheet
Shelves	Adjustable shelves
Energy Efficiency	Energy Star certified models available
