Page 10 / 35
INSTRUCTION MANUAL
SAFE 2010/MaxiSAFE 2010
81-09-IM.doc
Model 1.5 SAFE MaxiSAFE
External dimensions, DxWxH mm 895x1640x2000
Chamber dimensions, DxWxH mm 580x1500x725/650
Weight, kg 270
315
Spillage, litres 22.5
7.5
Exhaust volume, m
3
/h ± 10 %
500
Air velocity in-flow, m/s
≥ 0.4
Air velocity down-flow, m/s ± 20 %
0.4
Noise level, DIN dB(A); EN ISO 3744 58
59
Light intensity, Lux >1200
Supply Voltage/frequency, Volts/Hz 230/50
Power consumption, Watts 700
Required fusing Fuse T16A or circuit breaker 16A
Input current, A 2.6
Socket outlet(s), Volts/Hz/Amps 230/50/4
Maximum leakage current, mA 0.7
Model 1.8 SAFE MaxiSAFE
External dimensions, DxWxH mm 895x1940x2000
Chamber dimensions, DxWxH mm 580x1800x725/650
Weight, kg 300
355
Spillage, litres 27
9
Exhaust volume, m
3
/h ± 10 %
600
Air velocity in-flow, m/s
≥ 0.4
Air velocity down-flow, m/s ± 20 %
0.4
Noise level, DIN dB(A); EN ISO 3744 58
59
Light intensity, Lux >1200
Supply Voltage/frequency, Volts/Hz 230/50
Power consumption, Watts 800
Required fusing Fuse T16A or circuit breaker 16A
Input current, A 3.0
Socket outlet(s), Volts/Hz/Amps 230/50/4
Maximum leakage current, mA 0.7
