Page 32 / 35
INSTRUCTION MANUAL
SAFE 2010/MaxiSAFE 2010
81-09-IM.doc
Small screwdriver for slotted screws.
Fuses (see the Instruction Manual).
Procedure for replacement of fuses
Turn the fuse retainer counter-clockwise, remove the fuse and replace it.
11.5. Fluorescent light tube
Figure 11.
Equipment required
Phillips screwdriver.
Fluorescent light tube.
Procedure for fluorescent light tube replacement
1. Remove the reflector by lifting it and then pulling it out.
2. Unscrew the 2 screws to the left and take the fitting out.
3. Exchange the Light tube.
4. Reassemble in reverse order.
