Table 15. Removal steps of PCI Express Mini Card for wireless LAN (continued)
Half size PCI Express Mini card:
In step 1, unplug the jacks by using the removal tool antenna RF connector
(P/N: 08K7159) or pick the connectors with your fingers and gently unplug
them in direction of the arrow.
2
2
1
Step Screw (quantity) Color Torque
2 M2 × 3 mm, flat-head, nylon-coated (2) Silver 0.167 Nm
(1.7 kgfcm)
3
96 ThinkPad R500 Hardware Maintenance Manual
