T
able
29.
Removal
steps
of
LCD
panel,
LCD
cable,
hinges,
and
ALPET
sheets
(continued)
Remove
the
ALPET
sheets,
b
and
c
.
b
7
Note:
The
ALPET
sheets
are
secured
with
a
double-faced
adhesive
tape.
8
c
9
Removing
and
replacing
a
FRU
133
