Table12.RemovalstepsofPCIExpressMiniCardforwirelessLAN(continued)
1a
1b
2
StepScrew(quantity)Color
Torque
2
M2×3mm,small-head,nylon-coated(1)Silver
0.181Nm
(1.85kgfcm)
3
Wheninstalling:
ForThinkPadX100e:PlugthegraycableintothejackmarkedMAINorM,andtheblackcableintothejack
markedAUXorAonthecard.
ForThinkPadX120e:Plugthewhitecableintothejackmarked1orM,andtheblackcableintothejack
marked2orAonthecard.
Chapter8.RemovingandreplacingaFRU61
