ThinkPad X100e - 2090 Antenna Kit and LCD Rear Cover Assembly

Table28.RemovalstepsofLCDpanel,hinges,andLCDcable(continued)
3
M2×4mm,wafer-head,nylon-coated(6)Silver
0.181Nm
(1.85kgfcm)
Wheninstalling:WhenattachingtheLCDpaneltothecover,presstheleftandrightedgescoveredwithmetal
gentlywithyourngers.DONOTpressthesurfaceofthepanelorapplyanyexcessiveforcetothepanel.
4
4
4
4
5
5
StepScrew(quantity)Color
Torque
4
M2×3mm,wafer-head,nylon-coated(4)Silver
0.181Nm
(1.85kgfcm)
6
7
8
2090AntennakitandLCDrearcoverassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage54
•“1020Bottomdoor”onpage55
•“1030Harddiskdrive(HDD)”onpage58
•“1080Keyboard”onpage64
•“1090Palmrestassembly,power-onboardassembly(withcable),andmicrophone”onpage67
•“1100CRTboardassembly(withcable)”onpage72
Chapter8.RemovingandreplacingaFRU89
