ThinkPad X100e - 1070 Bluetooth Daughter Card (BDC-2)

Table13.RemovalstepsofPCIExpressMiniCardforwirelessWAN(continued)
3
Note:PlugtheredcableintothejackmarkedMAIN,andthebluecableintothejackmarkedAUXonthecard.
1070Bluetoothdaughtercard(BDC-2)
ForThinkPadX100e:
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage54
•“1020Bottomdoor”onpage55
Table14.RemovalstepsofBDC-2forThinkPadX100e
1
2
StepScrew(quantity)Color
Torque
Chapter8.RemovingandreplacingaFRU63
