ThinkPad X100e - 1100 CRT Board Assembly (with Cable)

Table18.Removalstepsofpalmrestassembly,power-onboardassembly(withcable),andmicrophone(continued)
1
2
Wheninstalling:Makesurethatalltheprojectionsofthepalmrestassemblyareattachedrmlytotheguide
holesofthebasecover.
1100CRTboardassembly(withcable)
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage54
•“1020Bottomdoor”onpage55
•“1030Harddiskdrive(HDD)”onpage58
•“1080Keyboard”onpage64
•“1090Palmrestassembly,power-onboardassembly(withcable),andmicrophone”onpage67
