Table27.Removalstepsofintegratedcamera
2
1
Wheninstalling:Makesurethattheconnectorisattachedrmly.
2030LCDpanel,hinges,andLCDcable
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage54
•“1020Bottomdoor”onpage55
•“1030Harddiskdrive(HDD)”onpage58
•“1080Keyboard”onpage64
•“1090Palmrestassembly,power-onboardassembly(withcable),andmicrophone”onpage67
•“1100CRTboardassembly(withcable)”onpage72
•“1110Speakerassembly”onpage73
•“1120I/Oboard(forThinkPadX120e)”onpage74
•“1130Systemboard,fanassembly,andbackupbattery”onpage75
•“2010LCDbezelassembly”onpage85
