ThinkPad X100e - 1060 PCI Express Mini Card for Wireless WAN

1060PCIExpressMiniCardforwirelessWAN
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage54
•“1020Bottomdoor”onpage55
Table13.RemovalstepsofPCIExpressMiniCardforwirelessWAN
Instep1aand1b,unplugthejacksbyusingtheremovaltoolantennaRFconnector(P/N:08K7159)orpickthe
connectorswithyourngersandgentlyunplugthemindirectionofthearrow.
2
1a
1b
StepScrew(quantity)Color
Torque
2
M2×3mm,small-head,nylon-coated(1)Silver
0.181Nm
(1.85kgfcm)
62HardwareMaintenanceManual
