•“1010Batterypack”onpage54
•“1020Bottomdoor”onpage55
•“1030Harddiskdrive(HDD)”onpage58
•“1080Keyboard”onpage64
•“1090Palmrestassembly,power-onboardassembly(withcable),andmicrophone”onpage67
Table20.Removalstepsofspeakerassembly
3
3
2
2
1
StepScrew(quantity)Color
Torque
2
M2×4mm,wafer-head,nylon-coated(2)Silver
0.181Nm
(1.85kgfcm)
Wheninstalling:Makesurethattheconnectorisattachedrmly.
1120I/Oboard(forThinkPadX120e)
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage54
•“1020Bottomdoor”onpage55
•“1030Harddiskdrive(HDD)”onpage58
•“1080Keyboard”onpage64
•“1090Palmrestassembly,power-onboardassembly(withcable),andmicrophone”onpage67
74HardwareMaintenanceManual
