ThinkPad X100e - 1150 DC-In Cable and Base Cover Assembly

Table24.RemovalstepsofLCDunit(continued)
3
3
3
StepScrew(quantity)Color
Torque
3
ForThinkPadX100e,M2×4mm,wafer-head,nylon-coated(3)
ForThinkPadX120e,M2.5×4mm,wafer-head,nylon-coated(3)
Silver
0.181Nm
(1.85kgfcm)
4
4
1150DC-incableandbasecoverassembly
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage54
•“1020Bottomdoor”onpage55
•“1030Harddiskdrive(HDD)”onpage58
•“1080Keyboard”onpage64
•“1090Palmrestassembly,power-onboardassembly(withcable),andmicrophone”onpage67
