•“1100CRTboardassembly(withcable)”onpage72
•“1110Speakerassembly”onpage73
•“1120I/Oboard(forThinkPadX120e)”onpage74
•“1130Systemboard,fanassembly,andbackupbattery”onpage75
Table25.RemovalstepsofDC-incableandbasecoverassembly
1
2
3
Note:Applyinglabelstothebasecover
ForThinkPadX100e
ThenewbasecoverFRUisshippedwithakitcontaininglabelsofseveralkinds.Whenyoureplacethe
basecover,youneedtoapplythefollowinglabels:
2
Homologationlabel
3
FFClabel
5
Certiedlabelunderbattery
6
Serialnumberbarcodeblanklabel
9
Informationlabelunderdoor
10
SIMinformationlabelunderdoor
Followinglabelsneedtobepeeledofffromtheoldbasecover,andneedtobeputonthenewbasecover.
1
Windowslicenselabel(COA)(onlyforWindows7models)
4
Ethernetlabel
7
WirelessWANlabel
8
ChinaWirelessWANlabel
Forsomemodels,youalsoneedtoapplyoneortwoFCClabels.Checktheoldbasecover;ifithasoneor
twoFCClabels,ndduplicatesoftheminthelabelkitandapplythemtothenewbasecover.
Forthelocationofeachlabel,referthefollowinggure:
Chapter8.RemovingandreplacingaFRU83
