•“1110Speakerassembly”onpage73
•“1120I/Oboard(forThinkPadX120e)”onpage74
•“1130Systemboard,fanassembly,andbackupbattery”onpage75
•“2010LCDbezelassembly”onpage85
•“2030LCDpanel,hinges,andLCDcable”onpage87
Table29.RemovalstepsofantennakitandLCDrearcoverassembly
1
1
2
2
3
3
4
4
Wheninstalling:Whenyouinstalltheantennakit,routethecablesasshownintheguresbelow.Asyouroutethe
cables,makesurethattheyarenotsubjectedtoanytension.Tensioncouldcausethecablestobedamagedby
thecableguides,orawiretobebroken.
a:WirelessLANAUXantenna(black)andwirelessWANAUXantenna(blue)
b:WirelessLANMAINantenna(gray)andwirelessWANMAINantenna(red)
a b
90HardwareMaintenanceManual
