66
12. Specifications
To see the product specifications, refer to the following table.
Item Specification Remarks
Model name QX800
Dimension / Weight 111.7 X 64 X 33 mm / 143.5 g Rear camera: 25 Ø X 32.3 X 61 mm / 25 g
Display panel TSP LCD (480 X 320 HVGA) IPS type
Memory SD memory card 32 / 64 / 128 GB
Recording mode
Continuous Rec
Records videos in 1-minute segments (dual
channels are supported for recording the front
and rear view)
Incident Rec
Records 10 seconds before and after the incident
(total 20 seconds)
Manual Rec
Records 10 seconds before and after manually
starting the recording (total 20 seconds)
Parking Rec (parking mode) Requires the continuous power cable installation
Camera sensor 6 M pixels, 1/1.8" CMOS Rear camera: 4 M pixels, 1/3” CMOS
Image sensor Sony IMX178 Rear camera: OmniVision 4689
Angle of view
140° (based on the opposite angle),
1440p
Rear camera: 180° (based on the opposite angle),
1440p
Video
QHD (2560 X 1440 / H.264 / file
extension: MP4)
Applies equally to the front / rear recording
Frame rate Maximum 30 fps
Audio PCM (pulse code modulation)
Acceleration sensor Triaxial acceleration sensor (3D, ±3G) 5 levels for sensitivity adjustment available
Rear camera V-IN connector MINI USB 10-pin connector
GPS External GPS module (optional)
Safety driving section alert supported, stereo
socket 2.5 Ø / quadrupole
Power input DC 12 / 24 V supported Rear camera: DC 5 V
T/S connector
Left / Right directional signal cable of
the vehicle
Brake signal included, compatible with the BSD
OBD2 connector DriveX supported Stereo socket (2.5 Ø) / quadrupole
Power consumption 2 CH: 5.1 W / 1 CH: 3.8 W (mean)
Except for the fully charged supercapacitor / the
LCD OFF status / GPS
Auxiliary power unit Supercapacitor
