This menu is used to invert the phase of the input signal. Press [A] or [B] to activate the edit
mode for channel A or B and to open the ‘INPUT A/B’ menu. Press [ENTER] to make the relevant
settings in the ‘Phase’ menu.
Use [PM2] or [PM3] to adjust the phase of the input signal as required. Confirm the new setting
with [ENTER].
Pressing [ESC] exits the menu item.
In this menu, you can adjust the runtime delay. Press [A] or [B] to open the ‘INPUT A/B’ menu.
Press [ENTER] to adjust the runtime delay in the ‘Delay’ menu.
Press [ENTER] and use [PM2] to roughly adjust the runtime delay, or use [PM3] to finely adjust it.
Confirm the new setting with [ENTER].
Pressing [ESC] exits the menu item.
This menu is used to make the settings of the compressor. Press [A] or [B] to activate the edit
mode for channel A or B and to open the ‘Input A/B’ menu. Press [ENTER] to make the relevant
settings in the ‘RMS CMP’ menu.
Use [NAV/PAR1] to change the level to be edited; use [PM2] or [PM3] to change the displayed
parameters ‘Bypass’, ‘Threshold’, ‘Ration’ and ‘Knee’ or ‘Release’ and ‘Attack’. Confirm to save
the new setting with [ENTER]. Pressing [ESC] exits the menu item.
"Phase"
"Delay"
"RMS Compressor"
Operating
digital speaker management system
38
