This menu is used to edit the phase of the output channel. Press the button of the output
channel [1] - [6] you want to edit in order to activate the edit mode for the relevant channel.
Press [ENTER] to change the phase in the ‘Phase’ menu.
Use [PM2] or [PM3] to change the phase (normal or inverted). Pressing [ESC] exits the menu
item.
This menu is used to edit the runtime delay of the output channel. Press the button of the
output channel [1] - [6] you want to edit in order to activate the edit mode for the relevant
channel. Press [ENTER] to change the runtime delay in the ‘Delay’ menu.
Press [ENTER] and use [PM2] to roughly adjust the runtime delay, or use [PM3] to finely adjust it.
Confirm the new setting with [ENTER].
Pressing [ESC] exits the menu item.
This menu is used to make the settings of the compressor or limiter. Press the button of the
output channel [1] - [6] you want to edit in order to activate the edit mode for the relevant
channel. Press [ENTER] to make the relevant settings in the ‘RMS CMP’ or ‘PEAK LIM’ menu.
Use [NAV/PAR1] to change the level to be edited; use [PM2] or [PM3] to change the displayed
parameters ‘Bypass’, ‘Threshold’, ‘Ratio’ and ‘Knee’ (RMS compressor only) or ‘Release’ and
‘Attack’. Confirm to save the new setting with [ENTER]. Pressing [ESC] exits the menu item.
"Phase"
"Delay"
"Compressor/Limiter"
Operating
digital speaker management system
44
