thomann T.racks DSP 26 User Manual

With this menu you can activate bypassing of the equaliser (EQ). Press [A] or [B] to activate the
edit mode for channel A or B and to open the ‘Input A/B’ menu. Press [ENTER] to make the rele‐
vant settings in the ‘EQ BYP’ menu.
Use [PM2] or [PM3] to adapt the status of the equaliser as required. Confirm to save the new
setting with [ENTER]. Pressing [ESC] exits the menu item.
This menu can be used to edit a frequency range of the equaliser (EQ) for one input channel.
Press [A] or [B] to activate the edit mode for channel A or B and to open the ‘Input A/B’ menu.
Press [ENTER] to make the relevant settings in the ‘EQ-X’ menu.
Use [PM2] to change the status of the EQ band (bypass or On), and [PM3] to change the filter
type. Press [ENTER] to move to the next level.
Now use [NAV/PAR1] to change the frequency (‘Freq’), [PM2] to change the quality (‘Q’), and
[PM3] to change the accentuation / attenuation (‘Gain’).
Pressing [ESC] takes you back to the first level. Pressing [ESC] again exits the menu item.
"EQ Bypass"
"EQ-X"
Operating
DSP 26
39
