THORLABS K-Cube Piezo Controller User Manual

35
Chapter 5 Operation - Tutorial
5.1 Introduction
The following brief tu torial guides the user through a typ ical series of actions and
parameter adjustments performed using the PC based APT software. It assumes that
the unit is electrically connected as shown in Section 3.3. and that the APT Software
is already installed - see Section 3.1. It al so assumes that a pie zo actuator is
connected to the ‘HV OUT connector on the rear panel.
5.2 Using the APT User Utility
The APT User.exe application allows the user to interact with any number of APT
hardware control units connected to the PC USB Bus (or simulated via the APTConfig
utility). This program allows multiple graphical instrument panels to be displayed so
that multiple APT units can be controlled. All basic operating parameters can be set
through this program, and all basic operations (such as piezo moves) can be initiated.
Hardware configurations and parameter settings can b e saved to a file, which
simplifies system set up whenever APT User is run up.
This tutorial shows how the APT User application provides all of the functionality
necessary to operate the APT hardware.
1) Run the APT User program - Start/All Programs/Thorlabs/APT User/APT User.
The APT server registers automatically the units connected on the USB bus and
displays the associated GUI panels as shown in Fig. 5.1
