THORLABS K-Cube Piezo Controller User Manual

66
Appendix C Specifications and Associated
Products
C.1 Specifications
Parameter Value
Piezoelectric Output
Piezo Drive Voltage 0 - 150V max. (SMC Connector)
Piezo Drive Current 7.5mA max. continuous
User Voltage Control Digital Potentiometer (Resolution Selectable)
Output Noise No Load Condition: < 5mV rms
With 3.6 µF Load: < 3mV rms
Typical Piezo Capacitance 1µF to 10µF
Drive Bandwidth 1kHz (1µF Load, 1V p-p)
Drive Input 0-10V (SMA Connector)
Output Monitor 0-10V (SMA Connector)
Voltage Readout 5 Digit 7 Segment LED Display
USB Port Version 2.0 (mini) Compatible
K-Cube Controller Hub Connector 26-way ERNI
Closed Loop Operation with K-Cube Strain Gauge Reader
(KSG101)
Input Power Requirements (DIN Connector)
Voltages +15V (220 mA),
-15V (50 mA),
+5V (350 mA)
General Data
Housing Dimensions (W x D x H)
Excluding Buttons and Baseplate
60 x 60 x 47 mm (2.36" x 2.36" x 1.86")
Weight: 140g (5.0 oz)
