OPERATING MANUAL NBS TECHNOLOGY
ThyssenKrupp Aufzugswerke GmbH
3.2 Mounting the NBS, TW63
Mounting, see Fig. 3.1
Designation Unit
Manufacturer Warner Electric Europe Chr.Mayr GmbH
Type
Warner SZ1700/1700 Nm
1)
Mayr RSO800/2200 Nm
Braking torque [Nm] 1700 2200
Braking torque setting not possible not possible
Design 2-surface disc brake 4-surface disc brake
Version of brake linings asbestos-free asbestos-free
Brake disc diameter [mm] 275 275
Air gap [mm] 0.35 + 0.05 / - 0.1 0.65
Air gap setting not possible not possible
Electrical ventilation
1 magnetic clamp with
armature base plate
1 magnetic clamp with
armature base plate
180 - over-excitation 207 - over-excitation
90 - retentive voltage 104 - retentive voltage
1.32 - over-excitation 1.99 - over-excitation
0.67 - holding current 0.99 - holding current
238 - over-excitation 412 - over-excitation
60 - stopping power 103 - stopping power
Temperature monitoring
(PTC thermistor 155°C)
Manual emergency release 3 x M8 screws 2 x M12 screws
Connection cable length [m] approx. 0.5 approx. 1.0
Type of protection IP54 IP54
Weight [kg] approx. 45 approx. 75
Type approval code ABV 590/2 ABV 762/2
ESV 590/4 ESV 762/1
200 / 275 / 350 35 / 90 / 180
TW63_30501_ENG
[W]
Release monitoring (microswitch)
Technical data
Monitoring devices
[VDC]Operating voltage
Performance data
TW63-RSO800/2200 Nm
Operating current [A]
2) DC - direct current cut-off (emergency stop)
923912/2
1) Version will be replaced from 04/2012
with Mayr RSO800/2200 Nm
Type approval code
with response times
t10 / t50 / t90 2)
[ms]
Certificate for traction sheave shaft
Test number
28
10-2012
