3.3 Mounting the NBS, TW130
Mounting, see Fig. 3.1
Designation Unit Technical data
Manufacturer Warner Electric Europe Chr.Mayr GmbH
Type
Warner SZ2500/3000
Nm
1)
Mayr RSO1300/4000
Nm
Braking torque [Nm] 3000 4000
Braking torque setting not possible not possible
Design 4-surface disc brake 4-surface disc brake
Version of brake linings asbestos-free asbestos-free
Brake disc diameter [mm] 275 283.5
Air gap [mm] 0.45 + 0.1 / - 0.05 0.65 - 0.1 / + 0.15
Air gap setting not possible not possible
Electrical ventilation
1 magnetic clamp with
armature base plate
1 magnetic clamp
with armature base
plate
Operating voltage [VDC]
180 - over-excitation 207 - over-excitation
90 - retentive voltage
104 - retentive
voltage
Operating current [A]
1.32 - over-excitation 2.96 - over-excitation
0.66 - holding current 1.49 - holding current
Performance data [W]
238 - over-excitation 613 - over-excitation
59.5 - stopping power 155 - stopping power
Monitoring devices
Release monitoring (microswitch)
Temperature monitoring
(PTC thermistor 155°C)
Manual emergency release 3 x M8 screws 2 x M16 screws
Connection cable length [m] approx. 0.5 approx. 1.0
Type of protection IP54 IP54
Weight [kg] approx. 60 approx. 107
Type approval code ABV 592/1 ABV 891
Type approval code ESV 592/1 ESV 891
with response times
t10 / t50 / t90
2)
[ms] 250 / 350 / 450 115 / 190 / 300
Certificate for traction sheave shaft
923912/3
TW130-
RSO1300/4000 Nm
Test number
1)
Version will be replaced from 08/2012 with Mayr
RSO1300/4000 Nm
TW130_30501_ENG
2)
DC - direct current cut-off (emergency stop)
