Installation and Operational Instructions
for ROBA-stop
®
-silenzio
®
Type 896.213.30
Sizes 500 – 1800
Chr. Mayr GmbH + Co. KG Tel.: +49 8341 804-0 E079 10 228 000 471
Eichenstraße 1 Fax: +49 8341 804-421 Page 6 of 17
D-87665 Mauerstetten www.mayr.com
Germany E-Mail: info@mayr.com 21/06/2012 TK/HW/GF/SU
Brake Illustrations Size 500
Fig. 1 Fig. 2
Brake Illustrations Size 800
Fig. 3 Fig. 4
16
14
15
9
4
4.1
12
8
7
2
1
10
3
18
5.3
17
Air gap "a"Cable length approx. 1000 mm
Not included in delivery
16
14
15
9
4
4.1
12
8
7
2
1
10
3
18
5.3
17
Air gap "a"Cable length approx. 1000 mm
Customer-side shaft
Not included in delivery
