Thytronic NC020 - Menu Tree

SETTING AND COMMISSIONING
67
NC020 - Manual - 05 - 2022
7.3 MENU TREE
READ
NC020_read.ai
Clock
Counters
PROCEED SET MENU’
INFO
Firmware Release
1.0
Nominal freq 50 Hz
Serial 555555
Code NC020-MB0-a
IN Compensation
INC MOD calib
0.00000 A/INn
INC PHI calib
0.0 deg
MEASURES
INnp value 100
INnp unit A
Reading Relative
IEC 0.0000 A/In
V1 0.0000 Vn
V2 0.0000 Vn
IL1 0.0000 A/In
IN 0.00000 A/INn
INC 0.00000 A/INn
IN PHI 0.0 deg
IL2 0.0000 A/In
IL3 0.0000 A/In
IL1RMS 0.0000 A/In
IL2RMS 0.0000 A/In
IL3RMS 0.0000 A/In
V3 0.0000 Vn
Inp value 300
Inp unit A
Year
Month
Day
Hour
Minute
Second
Protection trip
None
TD Discharge
Discharging... 0 s
Circuit breaker
Position Closed
Self-test
Self-test None
Counter ST I> 0
Counter ST I>> 0
Counter ST I>>> 0
Counter ST IE> 0
Counter ST IE>> 0
Counter ST IN>AL 0
Counter ST IN> 0
Counter ST IN>> 0
Counter ST U> 0
Counter ST U>> 0
Counter ST U>>> 0
Counter ST I<< 0
Counter TR I> 0
Counter TR I>> 0
Counter TR I>>> 0
Counter TR IE> 0
Counter TR IE>> 0
Counter TR IN>AL 0
Counter TR IN> 0
Counter TR IN>> 0
Counter TR U> 0
Counter TR U>> 0
Counter TR U>>> 0
Counter TR I<< 0
Last fault
F - Number 20
F-Cause Trip I>>
F-Phases None
F-IL1 2.0016 In
F-IL2 2.0016 In
F-IL3 0.0000 In
F-IL1RMS 2.0016 In
F-IL2RMS 2.0016 In
F-IL3RMS 0.000 In
F-IEC 2.0000 In
F-INC 2.00000 In
F-V1 2.0000 Vn
F-V2 0.0000 Vn
F-V3 0.0000 Vn
F-Year 2012
F-Month 3
F-Day 8
F-Hour 10 h
F-Minute 20 m
F-Second 0 s
F-Millisecond 0 ms
Digital inputs
IN1-52b OFF
IN1-52a OFF
IN3-Reset OFF
