VPM-3400
Rev. fra 02- til
Pos. Itemno. Dansk English Deutsch
1 VHY-00101 Hydrostatpumpe Hydrostatic pump Hydrstatische Pumpe
1.1 25991001 O-ring lille (reguleringsaksel) O-ring small (reg. shaft) O-Dichtungsring klein
1.2 25991002 O-ring stor (reguleringsaksel) O-ring large (reg. shaft) O-Dichtungsring groß
1.3 VMO-00012 Koblingsdel hun Clutch part female Steckdose-Verbindungsteil
1.4 VMO-00008 Koblingsdel han Male clutch Stecker-Verbindungsteil
1.5 49901003 Bolt for kobling Bolt for clutch Verbindungsschraube
2 VHY-00103 Tandhjulspumpe Gear pump Zahnpumpe
3 711217-00 Olieslange 260mm Oilhose 260mm Ölschlauch 260mm
4 711216-00 Olieslange 620mm Oilhose 620mm Ölschlauch 620 mm
5 V3422 Hydr. slange 300mm Hydr. hose 300 Hydraulikschlauch 300mm
6 V34-390 Forreste motorophæng Engine mounting front Motoraufhängung
7 VIN-00010 Motorfødder Vibration absorbers Vibrationsdimmer
8 37301023 Prop Plug Stöpsel
9 711135-00 Neutraliseringskonsol Neutralization console Neutralisierungskonsole
10 VTR-00002 Leje Bearing Lager
11
12
13
14
15
16
17
18
19
20
21
22
23
Side 12.A
