C: Start The key is turned to this position in order to
start the diesel motor.
5. Multifunction lever with the functions stated below. They only work when the ignition is
on.
In order to activate the signal before overtaking - push the lever to the right.
To turn on the strong passing beam - push the lever to the left.
To activate the horn - push on the tip of the lever.
To activate the right blinker - push the lever forwards.
To activate the left blinker - pull the lever backwards.
6. Rod for keeping the brake pedal pressed down. The brake pedal stays down. When the rod
is pushed down, the pedal releases. The brake is activated, and it is deactivated again by
lightly pressing on the brake pedal.
7. The lights blink according to the activated blinker on the right and the left.
8. Light for the quick P-brake. It shines if the brake is activated.
9. This light indicates that the strong passing beam is turned on.
10. Preheater light. If the ignition key is in position B - preheating (see 4. Start switch), then
the preheater light shines. The preheater light will turn off automatically after about 5
seconds, and the diesel motor is ready to be started.
11. The charging light gives a warning if the electric charging system isn't working properly.
You may check the operation of the warning light by checking if the light is on when the key
is in position B (see 4. Start switch).
12. The oil pressure light warns you if the diesel motor lubricant pressure is too low. You
may check the operation of the warning light by checking if the light is on when the key is in
position B (see 16. start switch), without the diesel motor running.
13. The float position settings light. It shines if the float position is activated. The float
position is used if the tool attached in the front is supposed to copy the terrain (float).
14. Switch for changing the direction on the front power take off (PTO).
15. Switch with which the lifting arms are pushed down (the float position must be activated).
16. Switch for the front hydraulic power take off (PTO). The lever activates 2 big quick
couplings in the front on the hydraulics panel. Note: The machine cannot be started if this
switch is activated.
