MAINTENANCE

19

9.3 Cab

30. Air jet (page 25) 34. Reversing pedal (page 25)

31. Brake pedal (page 25) 35. Seat adjustment (page 25)

32. Adjusting the steering column (page 25) 36. Regulating arm rests (page 25)

33. Ground drive pedal (page 25)

34.

33.

32.

31.

30.

35.
