MAINTENANCE

23 LUBRICATION PLAN

2 pc on each lifting

cylinder

(50 hours)

2 pc – lifting arms.

Right and left side (50

hours)

2 pc – bends (10 hours)

1 pc rotating cylinder rod

eye (50 hours)
