10 MAIN SWITCH, FUSES AND RELAYS
10.1 Main switch
The machine is equipped with a main switch for the
electric system. It is located at the rear end of the
machine under the 7-pole plug. The main switch has
a removable key that can be removed as an additional
safeguard against theft.
Main switch with a key
10.2 Main fuse with two relays
IMPORTANT
Never replace the fuses with fuses that have a higher voltage. There is always a reason (cause)
for a blown fuse. Before fitting a new fuse, determine the cause and remove the problem.
Relay
The main fuse is located on the left side right behind
the battery (80 Amp).
