26. Switch for the double action outlet at the rear end of the machine. It is used i.e. to control
lifting and placing with the tipper.
27. 12V reversing switch. It is used e.g. for regulating the sprinkling speed if the sprinkling
device is regulated electrically.
28. 12 V switch in the trailer plug.
29. Power take off (PTO) switch at the rear. The machine cannot be started if this switch is
activated.
30. Air jet.
31. Brake pedal. It may be firmly secured and used as a p-brake.
32. Controller for adjusting steering column position.
33. Ground drive pedal. When the pedal is pressed, the machine starts to move forward. The
machine stops quite suddenly after the pedal is released.
34. Pedal for reversing. It works the same way as the ground drive pedal.
35. Controller for adjusting the arm rest position. If you release both star-shaped controllers,
the arm rest may be adjusted forwards or backwards.
9.6 Seat
It is a spring seat which may be adjusted for optimum driving comfort.
