Do not forget that if the terminal of the front power take off (PTO) is activated, the
diesel motor will stop, if the driver leaves the seat.
17. Joystick – control lever for operating the front jack and the double-action oil outlet in the
front.
The lifting arms will lift up if the lever is pulled back.
If the lever is pushed forward, the front jacks will be lowered. In this position
the lever will lock, and the float position will activate.
When attaching tools, you must use switch no. 15 as with the activation of the
float position. Then the hydraulic pressure will cause the front jack to lower.
Note: Do not use this function when driving with tools as it can cause damage to
the tool and the front jack.
Moving the joystick sideways will send oil to the double action oil outlet. The
direction of oil flow may be changed by moving the joystick from left to right
and vice versa.
18. Throttle handle for regulating the rotational speed of the diesel motor.
19. Light switch.
20. Air fan regulation. The air fan regulation has 4 levels, from 0 to 3. If the windows are
very misty and the fan is set to level 3, it might be appropriate to slightly open the side
window for a large amount of humid air to escapes out.
21. With this button, you regulate the heat intake.
22. Air conditioning regulation (additional equipment). With this button, you turn the air
conditioning ON/OFF and regulate the rate of cooling. We must warn you that the air
conditioning must at least be on level 1 in order to turn it on. The air conditioning can be
used to dehumidify windows in the winter. Regulation of the cooling rate is set to minimum
and heat regulation is set to maximum. Dry air is now fed into the cab and the moisture on the
windows quickly evaporates.
23. Switch for interval wiping. This switch can be used instead of the switch on the ceiling
panel if need be (see 40. wiper switch).
24. Switch for a 2 pole electrical plug on the front panel of the machine. Use this switch if a
tool, which has more functions on the double action oil outlet, is attached to the machine (e.g.
sweeping/suction or a snow blade). For example, the control lever controls the right side
brush if this switch is not activated and the left side brush if it is activated.
25. Switch for a 3 pole electrical plug on the front panel of the machine. It is used, among
other things, to control the rotational speed of the brushes if a sweeping/suction device is
attached.
