Assembly instructions
Sheath holding gasket:
- 2 O-rings Ø 4 mm
9
Ref: 55007196 come with
the frame.
They must be positioned on the brake sheath to
prevent it from moving during use.
The whole of the sheath is fed into the
frame, and it must not be interrupted.
