Time Scylon - Installing and Removing the Wheels on the Sylon Disc Frame

Assembly instructions
Wheel installation:
- Position the quick release lever
6
of the wheel
axle in the open position
7
.
Scylon 85.jpg
- Keep this lever
6
in open position,
and bring the fork
8
onto the wheel hub.
Scylon 86.jpg
- Engage the axis
9
in the wheel hub, until you hear
an audible "click".
- Turn the adjusting nut
10
to expand the red insert.
Scylon 87.jpg
Removing the wheels:
Remove in the reverse order of installation.
Always check the tightness of your wheels before each ride.
5.9.2 Installing and removing the wheels on the Sylon disc frame
TIME Sylon disc frames are equipped with wheel axles, with a quick-fastening through-axle system.
Before installing, read the wheel manufacturer's technical instructions.
NIM_Scylon-01
40
EN
