TMQ AP4 Autopilot (AP4S10) 11 of 62 Version 4.96 9/10/2017
Alarm will sound after set time has expired
Press TIMER to reset
When the commercial timer is enabled and the autopilot is in control of the boat
(i.e.: in AUTO, GPS or REMOTE AUTO mode), the AP4 internal alarm
sounds after completion of the selected interval and the louder external alarm
one minute later, unless the timer is previously reset.
In SET, PWR and remote POWER modes, the timer can be set to any required
time as for a pleasure boat.
Autopilot Operation - Remote Control
The following is a brief overview of the capabilities of the AP4 autopilot with
remote control units. Each is described in more detail later in the manual. The
RFU control mode must be selected in order to use the remotes, apart from the
front panel knob and the jog levers.
Hand Remote
Hand Remote Auto Steer
The AP4 can be controlled with a hand remote unit. Auto and power steer
modes can be selected. Special remote response mode r-1 must be set in AP4.
To engage auto steer mode with Hand Remote Unit
Switch AP4 MODE to SET, AUTO or PWR
Set remote knob to centre position
Switch remote switch to AUTO
Pilot locks on to boat heading as for normal autopilot
Change course by +/- 90 º by rotating knob
Note: If remote switch is already in the AUTO position, move switch to OFF
and then back to AUTO.
