TMQ AP4 - Set (Standby)

TMQ AP4 Autopilot (AP4S10) 6 of 62 Version 4.96 9/10/2017
 Set/Standby Mode
The digital display shows the current magnetic heading.
The autopilot does not apply any steering corrections.
 Auto Mode
The autopilot maintains your boat on the selected magnetic course.
Course can be set or changed by rotating the Course knob or from a
remote steering station.
 Power Steer
The rudder may be controlled by the course knob on the main panel or
from a remote steering station.
 GPS Mode
When receiving information from a GPS unit, the autopilot can steer a
vessel along a preset track to a precise latitude and longitude.
 Watch Timer
A timer can be set from 1 to 120 minutes. When the time expires, an
alarm sounds. Uses include timing of trawling runs or a reminder to
check for anchor drag at set periods.
 Commercial Watch Timer
For vessels under survey. The timer can be set to give a warning alarm
at a fixed preset time and provide an output control signal for a loud
external alarm 1 minute after the internal alarm sounds.
Note: External alarm piezo siren must be fitted
Set (Standby)
 MODE switch in SET position
 The AUTO light is off *
 The motor clutch is disengaged *
 No steering control output is generated *
 The digital display shows the vessels current magnetic course.
 Watch Alarm may be set (if required)
 Hand remote or steering lever (if installed) is ignored at first turn on.
