TMQ AP4 - Active Remote Auto Steer; Active Remote Power Steer; Active Remote GPS - Waypoint Steering

TMQ AP4 Autopilot (AP4S10) 13 of 62 Version 4.96 9/10/2017
Active Remote Auto Steer
Note: AP4 must be set to r-2 special remote mode
To engage auto steer mode with Active Remote Unit
 Switch AP4 MODE to SET, AUTO or PWR
 Set remote knob to centre position
 Press AUTO on active remote
 AUTO LED on AP4 will light
 Pilot locks on to boat heading as for normal autopilot
 Change course by +/- 90 º by rotating knob
To disengage auto steer mode with Active Remote Unit
 Press STANDBY on active remote
 Pilot is now in SET mode. AUTO LED is off
 Boat is now steered manually (by helm)
Active Remote Power Steer
To engage power steer mode with Active Remote Unit
 Switch AP4 MODE to SET, AUTO or PWR
 Set remote knob to centre position
 Press POWER STEER on active remote
 AUTO LED on AP4 will light
 AP4 display shows boat heading
 Boat can be steered by rotating active remote knob
To disengage auto steer mode with Active Remote Unit
 Press STANDBY on active remote
 Pilot is now in SET mode. AUTO LED is off
Boat is now steered manually (by helm)
Active Remote GPS – Waypoint Steering
To Engage GPS Mode
 Switch AP4 MODE switch to SET or AUTO
 Press GPS button on active remote
 GPS light on AP4 will light
