Installation of Rudder Feedback
Precautions
The rudder feedback unit is water resistant. However, if it is to be mounted in a
wet position, some effort is necessary to ensure the unit does not become
immersed in water. If necessary the standard rudder feedback unit may be
mounted upside down, in which case the feedback cable must be cut in a
suitably dry position, and the blue and red wires swapped.
Note: do not mount the heavy duty rudder feedback unit upside down.
Note: the autopilot will function with some restrictions if a rudder feedback
unit (RFU) is not fitted, or if the feedback is faulty or incorrectly
adjusted. In case of not fitting a RFU, the device must be set to work in
non RFU mode via special mode 922. See more details on page 52,
“Operating Without RFU” section.
