Users manual P/C: 3-001-0001
10
2.1.4. MC68HC705B16N/B32 (PLCC52)
TDO
XPROG-m
GND
B0
B1
B2
B3
B4
B5
B6
Vcc
VppR
B7
PD4
Optional-must be Hi
RDI
Optional-must be Hi
/RESET
PD3
VSS
+9V
VDD
PLCC52
/IRQ
Optional-must be Hi
XPROG pin
B0 B1 B2 B3 B4 B5 B6 B7 Vcc VppR
Signal level - 1 0/1 0/1 - 0/1 1 1 +5V±5% +9V±5%
2.1.5. MC68HC705B16N/B32 (QFP64)
PD4
+9V
Optional-must be Hi
/RESET
Optional-must be Hi
QFP64
Optional-must be Hi
RDI
TDO
Vdd
Vss
XPROG-m
GND
B0
B1
B2
B3
B4
B5
B6
Vcc
VppR
B7
TCAP1
PD3
/IRQ
XPROG pin
B0 B1 B2 B3 B4 B5 B6 B7 Vcc VppR
Signal level - 1 0/1 0/1 - 0/1 1 1 +5V±5% +9V±5%
Mask sets:
Oscillator: 16, 17 pin
Packages: PLCC52
EEPROM: 0x0101 – 0x01FF
CFG(EEPROM):
0x0100
Mask sets:
Oscillator: 28, 29 pin
Packages: QFP64
EEPROM: 0x0101 – 0x01FF
CFG(EEPROM): 0x0100
