TMT XPROG-m - 2.3.9. MC68 HC11 KA4(PLCC68); 2.3.10. MC68 HC11 KA4(QFP64)

XPROG-m © 2005
TMT
Users manual P/C: 3-001-0001
23
2.3.9. MC68HC11KA4(PLCC68)
VDD TxD
PLCC68
Optional-must be Lo
Optional-must be Lo
RxD
/RESET
MODB
VSS
XPROG-m
GND
B0
B1
B2
B3
B4
B5
B6
Vcc
VppR
B7
XPROG pin
B0 B1 B2 B3 B4 B5 B6 B7 Vcc VppR
Signal level - - 0/1 0/1 0 0/1 - - +5V±5%
2.3.10. MC68HC11KA4(QFP64)
QFP64
MODA
Vdd
XPROG-m
GND
B0
B1
B2
B3
B4
B5
B6
Vcc
VppR
B7
Optional-must be Lo
/RESET
Optional-must be Lo
RxD
TxD
Vss
MODB
XPROG pin
B0 B1 B2 B3 B4 B5 B6 B7 Vcc VppR
Signal level - - 0/1 0/1 0 0/1 - - +5V±5%
Mask sets: 0E57S
Oscillator: 56, 57 pin
Packages: PLCC68
EEPROM:
0x0D80 – 0x0FFF
Mask sets: 0E57S
Oscillator: 59, 60 pin
Packages: QFP64
EEPROM: 0x0D80 – 0x0FFF
