2.5. TMS370 family
The TMS370 family supported only by on board programming. The suitable
PLCC adapter must be mounted (see Figure 4).
Supported PLCC adapters shown in the Table 2.
Product code Type
1-002-0001 TMS370 PLCC28 programming adapter
1-002-0002 TMS370 PLCC44 programming adapter
1-002-0003 TMS370 PLCC68 programming adapter
Figure 4. The XPROG-m™ with PLCC adapter
PLCC adapter
Table 2. PLCC adapters
