2.1.11. MC68HC05V12

The MC68HC05V12 support on-board and ICP (in-circuit programming)

modes for reading and writing EEPROM data.

MC68HC05V12 on-board programming

The suitable programming adapter must be mounted (see Figure).

PLCC68

MC68HC05V12 programming adapter

P/C: 1-002-0009

Mask sets: 1H24M

Packages: PLCC68

EEPROM: 0x0240 – 0x033F
