Chapter 2 INDICATOR STATUS OF REMOTE MICROPHONES
1.15.IndicatorStateattheTimeofEmergencyReset
When the system is set to "Emergency," the emergency reset function can be assigned to the Function key.
Pressing the function-assigned key causes all the activated emergency broadcast patterns to stop, allowing the
emergency broadcast status to be reset after the restoration EV message broadcast completion.
The 2 indicators next to the Function key indicate the emergency reset state.
Notes
• Fortheemergencyfunctionsettings,seetheseparateSettingSoftwareInstructions,"BASICSETTINGS."
• For instructions on assigning functions to function keys, see the separate Setting Software Instructions,
"EVENT SETTINGS."
Restoration EV Message
Status Indicator
Key ON/OFF Indicator
Function key (Emergency reset key)
The meanings of the 2 indicators next to the Function key are as follows:
Indicator Status Meaning
Key ON/OFF Indicator Unlit
When the function key is not pressed
Lights green
When the function key is pressed
(as long as it is pressed)
Restoration EV Message
Status Indicator
Unlit
Restoration EV Message broadcast assigned to the function
key is being stopped.
Lights green
Restoration EV Message broadcast assigned to the function
key is being activated.
