3-9
Chapter 3 OPERATION
2. EMERGENCY WARNING BROADCAST
Youcanstartanemergencywarningbroadcastusingtheremotemicrophone’skey.Thepresetaudiosource
appliedtotheVX-3000F’sAudioinputcanbebroadcasttothepresetzoneswhilethekeyishelddown.
Emergency warning broadcast can be made even during power failure. When attenuators are used in the
broadcast zones, the emergency warning broadcast is made bypassing the attenuators and signal processing.
When the priority set to the emergency warning broadcast is higher than the emergency broadcast, the
emergency warning broadcast will override the emergency broadcast while left in the emergency mode even
during emergency broadcast. During general broadcast, the emergency warning broadcast will override the
general broadcast while left in the normal mode.
When the emergency warning broadcast is activated while the higher-priority broadcast is in progress, the
emergency warning broadcast is placed in standby, and will start after the higher-priority broadcast is complete.
[Operationexamplefortheemergencywarningbroadcast]
The example below shows the operation procedure when the "Emergency warning broadcast" is assigned to
theRM-300X’sEmergencykey.
Step 1. Open the cover, then continue to press the Emergency Warning Broadcast key.
The emergency warning broadcast continues and the Emergency warning broadcast indicator lights
red while the key is held down.
Cover
Emergency Warning Broadcast key
Lights red
Emergency warning
broadcast indicator
Cover
Goes out
Step 2. Release the Emergency Warning Broadcast key, then close the cover.
The emergency warning broadcast is terminated and the Emergency warning broadcast indicator will
go out.
