Chapter 2 INDICATOR STATUS OF REMOTE MICROPHONES
2.6.IndicatorStateattheTimeofRMBroadcastStatusDisplay
The Broadcast status indicator to the left of the Function key indicates the current broadcast status of other
Remote Microphone.
Note
For instructions on assigning functions to function keys, see the separate Setting Software Instructions, "EVENT
SETTINGS."
Broadcast Status Indicator
(Always unlit, not used)
Function key (RM broadcast status display key)
The meanings of the 2 indicators next to the Function key are as follows:
2.7.IndicatorStateattheTimeofLampTest
When the lamp test function has been assigned to the Function key, the 2 indicators to the left of the key
indicate the running status of the lamp test.
Pressing the Lamp Test key causes all indicators on the primary Remote Microphone to light, and the built-in
buzzer to sound.
Notes
• Forinstructionsonsettingthesurveillancefunction,seetheseparateSettingSoftwareInstructions,"BASIC
SETTINGS."
• ForthetypeoftheRM-300Xsettings,seetheseparateSettingSoftwareInstructions,"UnitConguration
Settings."
• For instructions on assigning functions to function keys, see the separate Setting Software Instructions,
"EVENT SETTINGS."
Lamp Test Indicator (L)
Lamp Test Indicator (R)
Function key (Lamp test key)
The meanings of the 2 indicators next to the Function key are as follows:
Indicator Status Meaning
Broadcast Status Indicator Unlit
When the Remote Microphone assigned to the function key
is not engaged in broadcasting
Lights yellow
When the Remote Microphone assigned to the function key
is engaged in broadcasting
Indicator Status Meaning
Lamp Test Indicator Unlit
When the function key is not pressed
Lights yellow
and green
Lamp test has been executed by pressing the function key.
