Recording Assistant
Recording Assistant battery
The battery compartment of the Recording Assistant is located on the back of the unit. Only use the batteries
provided with the Tobii Glasses (Varta EasyPack XL, 3.7 V). Battery life is dependent on usage and can last for up to
70 minutes of use. Read about Battery life on the next page.
To remove the battery:
1. Make sure the Recording Assistant is turned off before removing the battery.
2. Hold the unit with the front display facing the palm of your hand.
3. Open the battery compartment by pressing the bracket on the top of the cover down and pulling it out.
4. Pull the battery out.
Read about Hot Swapping the battery on page 16.
To insert the battery:
1. With the label facing down and the connection points towards the bottom of the Recording Assistant insert
the battery in the compartment at an angle starting at the bottom of the unit, press into place.
2. Place it in the housing so it sits flush with the casing. It might appear as a loose fit, but the battery cover will
secure it in place once closed.
3. Align the battery cover with the housing and insert the cover at an angle starting at the bottom of the unit.
4. Close the cover until it snaps into place.
Connecting the glasses
Connect the glasses before turning on the Recording Assistant. Plug the glasses connector (on the end of the
cable connected to the glasses) to the glasses port located on top of the Recording Assistant (see page 7). With
the display of the Recording Assistant facing up, the small arrows on the connector should be facing up as well. The
connector should easily snap into place.
Connecting the glasses
connector to the glasses port on
the Recording Assistant
